Indoor All-in-One Air Quality Monitoring Sensor for CO2,PM2.5,VOC

This all-in-one air quality transmitter detects multiple air quality parameters, including temperature, humidity, CO2, PM2.5, PM10, VOC, and formaldehyde, supporting up to 7 parameters. It offers optional isolated/non-isolated RS485 output with built-in Modbus protocol for real-time multi-point data detection. Both indoor and ceiling-mounted types can configure RS485 communication addresses via DIP switches. The product features a wide power supply range and comprehensive over-voltage and reverse polarity protection. It is ideal for multi-parameter air quality monitoring in commercial complexes, smart buildings, offices, hotels, airports, and schools.

Features

²  Built-in high-precision sensors - Provides stable and accurate air quality measurements, ensuring reliable monitoring for healthier indoor environments.

²  Multi-parameter detection and display - Simultaneously tracks and shows critical air quality indicators (temperature, humidity, CO2, PM2.5, PM10, VOC, Formaldehyde), offering comprehensive insights to improve indoor air quality.

²  Tri-color LED indicator with optional turn-off - Offers an easy-to-understand visual representation of air quality status, while the option to turn off the indicator ensures flexibility and comfort in different settings.

²  Versatile installation options - Suitable for various indoor or ceiling-mounted applications, providing flexible deployment across different environments such as homes, offices, and public spaces.

Specification

·         Application:  Commercial, Residential, Industrial Buildings

·         Power Supply:   12~36VDC / 24Vac

·         Ambiente Range:  0~50C&0~95% RH (no condensation)

·         Storage Range:  -20~60C&0~95% RH (no condensation)

·         Output Signal:  Isolated / Non-isolated RS485 Modbus

·         Response Time:  ≤10s(25℃, Slow flow air)

·         Protection Class:  IP30

·         Certification:  CE / RoHS

·         Warranty： 2 Years

Please feel free to contact us if you need any further information.
